Технические характеристики
USA: width 39.37", weight 4.7 oz/yd²
Technical data:
Width: 100 cm
Twill weave
Style 442
Yarn type (warp/weft): CF200 tex x CF200 tex
Number of ends (warp/weft): 4 x 4 ends/cm
Application:
Standard reinforcement fabric for modelling, motor sports, ship construction, and sporting equipment
Calculated data for hand laminates with 35 volume percent fibres:
Resin consumption: 184 g/m², laminate thickness: 0.257 mm, laminate weight: 344 g/m²
Выберите интересующий вариант
Carbon fabric 160 g/m² (twill) 100 cm, roll/ 4 m
В наличии - Арт.: 190225-NA-4
Не доступен для заказа
Carbon fabric 160 g/m², twill weave, roll/ 0,5 m
Carbon fabric 160 g/m², twill weave, roll/ 0,5 m
В наличии - Арт.: 190225-NA-0
Carbon fabric 160 g/m², twill weave, roll/ 1 m
Carbon fabric 160 g/m², twill weave, roll/ 1 m
В наличии - Арт.: 190225-NA-1
Carbon fabric 160 g/m², twill weave, roll/ 2 m
Carbon fabric 160 g/m², twill weave, roll/ 2 m
В наличии - Арт.: 190225-NA-2
Carbon fabric 160 g/m², twill weave, roll/ 3 m
Carbon fabric 160 g/m², twill weave, roll/ 3 m
В наличии - Арт.: 190225-NA-3
Carbon fabric 160 g/m², twill weave, roll/ 5 m
Carbon fabric 160 g/m², twill weave, roll/ 5 m
В наличии - Арт.: 190225-NA-5
Carbon fabric 160 g/m², twill weave, roll/ 10 m
Carbon fabric 160 g/m², twill weave, roll/ 10 m
В наличии - Арт.: 190225-NA-6
Carbon fabric 160 g/m², twill weave, roll/ 20 m
Carbon fabric 160 g/m², twill weave, roll/ 20 m
В наличии - Арт.: 190225-NA-7
Carbon fabric 160 g/m², twill weave, roll/ 50 m
Carbon fabric 160 g/m², twill weave, roll/ 50 m
В наличии - Арт.: 190225-NA-8
Carbon fabric 160 g/m², twill weave, roll/ 100 m
Carbon fabric 160 g/m², twill weave, roll/ 100 m
В наличии - Арт.: 190225-NA-9
